10×6 Tandem Axle Mower Trailer
A hot-dip galvanised 10×6 tandem mower trailer rated to 1990 kg ATM (990 kg payload), with a 3000 × 1800 × 1600 mm box, an enclosed aluminium mower box, a side toolbox and fold-down aluminium ramps.
Explore the CH Trailers range through CH Tools in Emerald. Contact our team to check availability and what is on the yard to view, or enquire in store about the right trailer for your needs.
See it in Emerald
CH Tools
58 Hospital Rd
Emerald QLD 4720
Hours
Mon–Fri 7:30am – 5pm
Sat 7:30am – 1pm
Ring the team
What it's for
The bigger mowing rig: room for two machines or a wide-deck zero-turn, with the same lock-up mower box and side storage.
How it differs
Longer and wider than the 8×5 mower trailer: a 3000 × 1800 × 1600 mm box against 2400 × 1500 × 1600, a longer side toolbox, the same 1990 kg ATM and the same mower-box opening; rated payload 990 kg against the 8×5's 1050 kg.
Specifications
| Model code | ST10X6MT |
|---|---|
| ATM (aggregate trailer mass) | 1990 kg |
| Payload | 990 kg |
| Axles | tandem |
| Deck / box (mm) | 3000 x 1800 x 1600 high (internal box) |
| Rims and tyres | 14" Sunraysia rims with light truck tyres |
| Suspension | 7-leaf 8 mm rocker roller springs |
| Chassis | Fully welded heavy duty box section with RHS tube chassis |
| Floor | 2.5 mm galvanised checker plate (box section) |
| Drawbar (mm) | 1900 |
Specifications as supplied for this model. Ask the team to confirm the details that matter for your job.
Trailers are not available to purchase online and there are no prices online. Ring, enquire or visit the yard in Emerald.
What to bring to an enquiry
What you plan to carry and how often, the vehicle you'll tow with, and where the trailer will live. The team can then talk through size, ATM and the options that suit the job.
What's on it
- Hot-dip galvanised
- 10" Swing up Jockey Wheel
- Rear access with fold-down aluminium ramps
- Internal Box Dimensions: 3000mm(L) x 1800mm(W) x 1600mm(H)
- Enclosed Aluminium Mower Box (Internal Clearance: 1770mm(L) x 700mm(W) x 1460mm(H))
- Aluminium Side Toolbox with Shelve for Whipper-snipers and other gear (Size: 2980mm(L) x 260mm(W) x 940mm(H))
- Side Climb-Up Ladder
- Fully Welded Heavy Duty Box Section with RHS Tube Chassis
- 2.5mm Thickness Galvanised Checker Plate for Trailer Box Section
- 1900mm Reinforced Ultra-long Draw Bar for Easy Manoeuvre & Reversing
- 3 x Additional Support Beams & Crossmembers in the A Frame
- 7-Leaf 8mm Rocker Roller Springs (Heavy Duty Suspension)
- 14" Sunraysia Rims and Light Truck Tyres
- 2 x 50mm Round Solid Axle
- Reinforced Under Floor with Extra Support Beams
- Tie Down Rails All Around
- ADR Approved LED Taillights
- ADR Standard Heavy-Duty Chain & Load Rated Shackle
- Flat 7 Pin Plug
